Smarttek Black Smart Hot Water System 4.3Lpm
Smarttek Black Smart Hot Water System
Features
Smarttek Black Smart Hot Water System
How to set up
Details & Specs
Enjoy hot water in any climate for your outdoor bathroom or kitchen when you’re away from the comforts of home with the Smarttek Black Smart Hot Water System from Smarttek.
This unit has been tested over 12,000 cycles to ensure that you can assemble, dismantle and use it over and over without a hassle. With two capacities available, the Smarttek Black produces 4.3L per minute of constant water flow with the included pump (up to 6L per minute maximum with an optional larger volume pump) and comes with a premium shower head with on/off twist control and two pressure settings. The Smarttek Black is built to last in the harsh Aussie climate, so it has a stainless-steel finish and a double powder coated rear housing. The LCD temperature display lets you set the perfect temperature, the temperature safety cut off switch prevents you from getting scalded, and it’s super easy for you to set up.
Just hang it up, connect the gas bottle with the hose, connect the shower hose and rose to the water outlet valve, connect the water source to the water inlet valve, insert two included batteries and you’re ready to go. Get dependable and portable hot water when you’re camping or caravanning, with the Black smart hot water system from Smarttek.
- Simple to setup and use
- Up to 4.3L of water flow per minute with the included pump
- Unit is capable of a maximum of 6l per minute with larger pumps
- Stainless steel finish and double powder coated rear housing
- Dust, wind, rain and shock resistant
- LCD temperature display
- Shower head on/off twist control and 2 pressure settings
- Battery powered ignition
- Inbuilt energy saving function
- High flow water pressure protection
- Automatic shut off and ignition when turned off from the shower head
- Temperature safety cut-off switch to prevent scalding
- LCC27 fitting to bottle
- Technical support available from 9am-7pm 7 days per week - 1300 119 906
- Warranty information can be found here
External Dimensions:
30L x 15W x 44H cm
Packed Dimensions:
30L x 15W x 44H cm
Weight:
5.308 Kg (shower unit not including fittings)
Shower Hose Length:
2 Metres Stainless Steel Hose
Pump Hose Length:
2m 8mm Suction to pump | 2m 8mm Outlet from pump | 1/2" BSP fitting
Cable Length:
2.5 Metres with On/Off Switch & Two Alligator Clamps
Material:
Heater: Stainless Steel, High Grade Stainless Steel Screws and Double Powder Coated Rear Housing | Pump: Metal Shell & Corrosion resistant ABS
Pump:
4.3 L/pm | 12V DC | Pumps up to 10m with maximum 3m rise
Fuel Type:
LPG Propane
Fuel Consumption:
Winter Mode: 28 Mj/h | Summer Mode: 9Mj/h
Ignition:
Automatic
Gas Fitting to Appliance:
3/8" SAE | Regulated hose included
Gas Fitting to Bottle:
LCC27
Input Power:
12V DC
Batteries:
2 x D Cell for Ignintion (Included)
Run Time:
Summer Mode: 50 Hours from a 9 Kg LPG Bottle | Winter Mode: 16 Hours from a 9 Kg LPG Bottle
Max. Heat Output:
42°C above ambient (Min water, Max Gas, Winter Mode) | 52°C Maximum
Flow Rate:
Up to 4.3 L/pm with included pump | Up to 6L/pm maximum with optional larger volume pump | Min. Flow 2L/pm
Water Pressure:
Min: 25kPa | Max: 750kPa
Warranty:
3 Year | 1 Year Parts & Labour + 2 Year Replacement Parts
Supplier Code:
SMA-BLK
Snowys Code:
144728
Staff tip:The Smarttek Black is supplied with an LCC27 Type 27 gas cylinder connection. This will only connect to a 4kg or 9kg gas cylinder with an LCC27 Type 27 cylinder valve. This connection will NOT connect (screw−in) to the old POL Type 21 gas cylinder valve.
Staff tip:Just to cover our bums, we should mention that the tripod stand isn't included and is available as a separate item.
Reviews
(5)
3.6
5
(5)
Q&A's (20)
Reduction of Water Flow1 answer
Hi, Do you have a (adjustable or non adjustable) pressure or flow rate reduction valve available as an accessory or can you recommend a supplier of such an item? Most of the time I will be using the water from an existing water tank with a water pressure pump fitted. However the pump has a flow rate of approx. 8L/M. I would like to reduce the flow to the Smarttek when using the water from this pump to 4-5 L/M, mainly to conserve water when off grid. Many thanks.
Tony - Safety Bay, WA(1 year ago)
G'day Tony,
We have just confirmed this with Smarttek and the unit itself reduces the water flow, so you won't need an additional flow rate reduction valve. Say if you plug in from your water tank or garden hose tap, it will only pump out anywhere from 2 - 6L/M as the unit itself has a water adjustment built in.
Lauren - Snowys(1 year ago)
gas conection1 answer
can you run this from a 3/8 sae 4kg bottle direct to the 3/8 gas inlet?
scott - Tecoma, VIC(2 years ago)
G'day Scott,
This Smarttek system uses a 3/8 SAE hose from the appliance to an LCC27 fitting to the gas bottle, the current hose wouldn't fit to a smaller gas bottle with a 3/8 fitting. You will need an adaptor to make this work, the Gasmate 3/8" BSPP LH TO LCC27 adaptor would work to connect this hose to the 4kg gas bottle.
Kaya - Snowys(2 years ago)
Temp rise spec +40c ?1 answer
Does anyone know or is Smarttek confident about the temp rise being at least 40c above ambient on max gas/min flow winter setting - i ask because i will be camping at place where water temp will be just above zero, and i need 40c water to be comfortable
Aaron - Alderly, QLD(5 years ago)
G'day Aaron,
Yes, Smartek is confident in its design, with the maximum water temperature of 42C above ambient. When the water is colder the unit will consume more gas but can reach the temperature you're indicating.
Leece - Snowys(5 years ago)
outside durability1 answer
Is this heater ok to leave out side when its raining, I guess the question is, is it water proof.
David - Adelaide, SA(5 years ago)
G'day David,
Smarttek hasn't got an official waterproof rating on the unit, they have however indicated that it is dust, wind and rain shock resistance. As there isn't any official rating, I'd recommend moving the unit under cover if it's raining.
Leece - Snowys(5 years ago)
Marinised pump?1 answer
I assume this pump is for fresh water only? As in, not to be used for salt water if using on a boat?
Sarah - Brisbane(5 years ago)
G'day Sarah,
Yes, this is correct, the pump is designed for freshwater use only. They've not been designed for use on boats, or with salt water.
Leece - Snowys(5 years ago)
Shower rose included1 answer
Hi is the shower rose included or sold separately?
Todd Barrett - Wandi, WA(5 years ago)
G'day Todd,
Yes, the shower rose is included with the 4.3Lpm System. It is supplied with a 2m shower hose, but you can purchase an optional 5m shower hose too.
Leece - Snowys(5 years ago)
Can it run on 12V instead of batteries?1 answer
Can the HWS unit be powered by 12V instead of batteries (referring to the HWS unit itself, not the pump)?
Greg - Port Macquarie(5 years ago)
G'day Greg,
The only thing the batteries on the unit itself are required for are the ignition, so, unfortunately, that can't be powered by 12V. It takes 2 x D-cell batteries, which will generally last quite a long time, and they're only powering it at start-up.
Leece - Snowys(5 years ago)
Higher volume pump1 answer
Hi, is it possible to order this unit with the higher volume - 6lpm - pump, or does it need to be bought separately meaning we would have two pumps, one of which we would never use. Thanks
Greg - Bega(5 years ago)
G'day Greg,
If you're wanting a high volume 6Lpm pump then you can purchase that combination directly, so that you only end up with one piump. You can find the 6Lpm version here.
Leece - Snowys(5 years ago)
LPG fitting1 answer
Can you remove the regulator from the standard hose and replace it with smarttec type 2 quick fit and connect it straight to my already regulated camper gas system.
Tom - Port Stephens(5 years ago)
G'day Tom,
You can connect this unit directly to a campers bayonet system by removing the hose and regulator. The gas fitting on the unit is 3/8" SAE, so you will likely already have a hose that will do the trick, if you don't have a hose then you can find them here. The quick connects aren't needed, but you could use those in the system too if you want an easier and quicker system set up.
Leece - Snowys(5 years ago)
regular hose fitting to the hot water outlet?1 answer
Can you screw on a regular garden hose fitting to the hot water outlet?
Paul - Parkinson(5 years ago)
G'day Paul,
You can attach a regular garden hose to the water inlet, however, the outlet will only fit the supplied 2m stainless steel hose and showerhead.
Leece - Snowys(5 years ago)
Using with mains water?1 answer
Is it possible to connect to a garden/caravan mains tap? Or does it only operate using water supplied via the 12v pump?
Ben - 3000(5 years ago)
G'day Ben,
Yes you can operate the Smarttek Black Unit using mains water with standard hose fittings.
Leece - Snowys(5 years ago)
Option for running cold water?1 answer
Is it possible to run straight cold water through the heater? I only need shower temp or cold for filling water bottles etc. Is this possible or do the injectors need to be running for the system to work?
Dave - Sydney(6 years ago)
G'day Dave,
I've just given our display model a go with the gas switched off and it will still run, however, I'm not sure it's something Smarttek would recommend. I'm not sure what you plan to do with the water bottles, but the pump and hoses aren't designed for pumping drinking water if that was your plan.
Leece - Snowys(6 years ago)
Can i recirculate the soapy water1 answer
i imagine if the pump can draw from various sources then if i showered in say a large trug then i could re draw the used water and shower all day for no excess water usage.
chris - allambie(6 years ago)
G'day Chris,
Great question! It's not recommended to continuously recycle soapy water as it may cause issues with the pump over time, which could void the warranty. If you do choose to recycle the water then a 'soapless' soap such as wilderness wash would be a good option.
Susie - Snowys(6 years ago)
Does this product have an Australian standards certificate 1 answer
I have been told that it may not be to Australia standards
Nicholas - PETRIE(6 years ago)
G'day Nicholas,
Yes the Smarrtek Hot Water System does meet Australian Standards. It's certified under the AS2658, you can read more about this over on the Smarttek FAQ's page.
Leece - Snowys(6 years ago)
No pump option?1 answer
Can this be purchased without the pump?
Henry - Canberra(6 years ago)
G'day Henry,
All of the Smarttek Hot Water Systems are supplied with a pump, so, unfortunately, no you won't be able to get your hands on just the unit itself from us direct, but you might be able to chat directly with Smarttek to see if they have any option available
Leece - Snowys(6 years ago)
Pump Type1 answer
Is the pump submersible or does it use two lengths of hose either side, one to water source and one to the unit? If submersible, does the pump size fit through the opening of a standard 20L jerry can?
Liam - Sydney(7 years ago)
G'day Liam,
The pump has two lengths of hose, one on either side of the pump. The hose used to draw the water has nothing on the end of it, so yes you can submerge it in a standard jerry can.
Leece - Snowys(7 years ago)
Pump Power Options1 answer
The pump comes with alligator clips for connection to the car’s battery but what other options are there for powering the pump? 1. Is connection to 12V power via a cig socket possible with the included cable? 2. Is connection to 240V power possible with the included gear?
Liam - Sydney(7 years ago)
G'day Liam,
The Black Smart Hot Water System pump is supplied with a cable that will connect using alligator clips, so if you wanted to connect it using a cig plug then you'll need to grab a Multi Cable Pack , which includes a cigarette plug, Anderson, alligator plugs and a 2.5m cable with switch.
Leece - Snowys(7 years ago)
Hanging Point on Rear?1 answer
I’m looking for a unit I can hang from a roof rack on the side of my 4WD when parked and in use. I assume the back of this unit has a simple hanging point if one wanted to avoid the proprietary stand?
Liam - Sydney(7 years ago)
G'day Liam,
Yes, there is a U-shaped handle on the back of the unit so you can hang it over something, or use it to attach to your roof rack using some clips or clamps.
Leece - Snowys(7 years ago)
3/8 Gas Bottle?1 answer
Is there any reason why the unit wouldn’t work if connected to a 3/8 inch gas bottle instead of POL by using either an adaptor or different hose?
Liam - Sydney(7 years ago)
G'day Liam,
You can absolutely connect the Smartttek Black Smart Hot Water System to a 3/8" bottle, you'll just need to run it through a 3/8" BSP LH to POL adapter.
Leece - Snowys(7 years ago)
Water source2 answers
Can it suck water from creeks or other sources? Or only a tank?
Raff - 2087(7 years ago)
G'day Raff,
Yep! This system can suck water from creeks, dams or other water sources, aswell as tanks or mains. It has pretty versitile application. The Smarttek Black Smart Hot Water System pumps water a distance of 10m, over a maximum 3m rise.
Lauren - Snowys(7 years ago)
Just as an addition, if you creek or other natural water source is particularly muddy, its recommended you invest in a Smarttek Hot Water System Filter
Lauren - Snowys(7 years ago)
